INSTALLATION 3
19
OPTIMASS 7000
www.krohne.com10/2015 - 4001016303 - MA OPTIMASS 7000 R03 en
3.4.3 Cross talk
Where more than one meter is being installed, a very high level of immunity to cross talk means
that the meters can be mounted within close proximity to each other. The meters can be
mounted either in series or parallel, as shown.
3.4.4 Flange connections
Tighten the flange bolts evenly and in turn.
Meters in series
INFORMATION!
Where the meters are installed in series, it is strongly recommended that the process pipe
diameter remains constant. For more information, please contact the manufacturer.
Meters in parallel
MA_OPTIMASS_7000_en_151026_4001016303_R03.book Page 19 Monday, October 26, 2015 4:44 PM
