Maximum end loadings
• These (axial) loads have been calculated, based on 316L schedule 40 process pipework,
where un-radiographed butt welds have been used in pipe joints.
• The loads shown are the maximum permitted static load. If loads are cycling (between
tension and compression) these loads should be reduced. For advice, consult the
manufacturer.
OPTIMASS 7300C- Aluminium converter
housing - heating jacket / insulation
40 55 T6 T80
70 T5 T95
100 T4 T125
145 T3 - T1 T170
50 70 T4 T95
100 T3 - T1 T125
60 60 T4 - T1 T85
65 1 65 T4 - T1 T90
OPTIMASS 7300C - Stainless Steel
converter housing - no heating jacket /
insulation
40 55 T6 T80
75 T5 T95
120 T4 T130
150 T3 - T1 T160
50 75 T5 T95
115 T4 T130
135 T3 - T1 T145
55 55 T4 - T1 T80
OPTIMASS 7300C - Stainless Steel
converter housing - heating jacket /
insulation
40 55 T6 T80
70 T5 T95
100 T4 T125
145 T3 - T1 T170
50 70 T5 T95
75 T4 - T1 T100
55 55 T4 - T1 T80
1 depending on I/O option. Please call for more information.
Size 06 10 15 25 40 50 80
Titanium
TitaniumTitanium
Titanium
Flanges 19kN 25kN 38kN 60kN 80kN 170kN 230kN
Hygienic (all connections) 1.5kN 2kN 5kN 9kN 12kN 12kN 30kN
Stainless Steel / Hastelloy
Stainless Steel / HastelloyStainless Steel / Hastelloy
Stainless Steel / Hastelloy® / Tantalum
/ Tantalum / Tantalum
/ Tantalum
Flanges 19kN 25kN 38kN 60kN 80kN 80kN 170kN
Hygienic (all connections) 1.5kN 2kN 5kN 9kN 12kN 12kN 18kN
CAUTION!
The maximum permitted end loading on size 15 meters fitted with
½¨ ASME flanges is 19kN
