Krone EasyCut 3201 CV User Manual

Maintenance
74
Pos: 26.36.10 / BA/Wartung/Mä hwerke/Messerschr aub / Mess erschnellverschlus s/Messersch nellverschluss H altebolzen 14mm @ 0\mod_1 19726808787 5_78.docx @ 1 6444@ @ 1
10.11.3 Blade Quick-Fit Device
Danger! - Insufficient thickness of material on the retaining bolts.
Effect: Danger to life or serious injuries.
• At every blade changing check the thickness of the holding bolts material.
• Damage or worn retaining bolts must always be replaced by sets on each cutting
disc/blade drum!
• The material thickness of the retaining bolts must not be less than 14 mm at the weakest
point.
• The material thickness of the leaf spring must not be less than 3 mm at the weakest
point.
EC-239-0
min. 14 mm
Fig. 45
