Operating the BP50 page 11
Optional stand with lifting device
1. Loosen the fixing screw for the standard arm.
2. Feed the arm of the stand into the opening in the lifting device. Fix the arm with
the help of the fixing screw.
Area for placing the
sample vessel
Fixing screw for the
standard arm
Opening for
standard arm
Scew for lifting and
lowering
