8 Servicing/Maintenance
47 of 60
DN BOA-SuperCompact
35)
5.1301
36)
BOA-Compact
37)
5.1301
36)
BOA-W
5.1301
36)
BOA-H
5.1301
36)
BOA-R
5.1301
36)
BOA-S
5.1301
36)
BOA-RVK
80 4x M16x150 4x M16x55 4x M16x55 - 4x M16x60 4x M16x50 4x M16x100
100 4x M16x180 4x M16x55 4x M16x55 - 4x M16x60 4x M16x50 4x M16x110
125 8x M16x200 8x M16x60 8x M16x60 - 8x M16x65 8x M16x55 8x M16x150
150 8x M16x220 8x M16x60 8x M16x60 - 8x M16x65 8x M16x55 8x M16x160
200 8x M16x70 8x M16x70 8x M16x70 - 8x M16x65 8x M16x60 8x M16x200
Table42: Bolt sizes and lengths to DINEN1092-2 PN10
DN BOA-SuperCompact
35)
5.1301
36)
BOA-CompactEKB
5.1301
36)
BOA-W
5.1301
36)
BOA-H
5.1301
36)
/5.
3103
38)
BOA-R
5.1301
36)
BOA-S
5.1301
36)
/5.310
3
38)
BOA-RVK
15 - 4x M12x45 - - - - 4x M12x65
20 4x M12x90 4x M12x50 - - - - 4x M12x70
25 4x M12x90 4x M12x50 - - - - 4x M12x75
32 4x M16x100 4x M16x55 - - - - 4x M16x85
40 4x M16x110 4x M16x55 - - - - 4x M16x90
50 4x M16x120 4x M16x55 - - - - 4x M16x100
65 4x M16x140 4x M16x55 - - - - 4x M16x100
80 8x M16x160 8x M16x60 - - - - 8x M16x110
100 8x M16x180 8x M16x65 - - - - 8x M16x120
125 8x M16x200 8x M16x65 - - - - 8x M16x160
150 8x M20x240 8x M20x70 - - - - 8x M20x175
200 8x M20x80 8x M20x75 - - - - 8x M20x220
Table43: Bolt sizes and lengths to DINEN1092-2 PN16
DN BOA-SuperCompact
35)
5.1301
36)
BOA-Compact
37)
5.1301
36)
BOA-W
5.1301
36)
BOA-H
5.1301
36)
/5.3103
38)
BOA-R BOA-S
5.1301
36)
/5.310
3
38)
BOA-RVK
15 - 4x M12x45 4x M12x45 4x M12x45 4x M12x45 4x M12x45 4x M12x65
20 4x M12x90 4x M12x50 4x M12x50 4x M12x50 4x M12x50 4x M12x50 4x M12x70
25 4x M12x90 4x M12x50 4x M12x50 4x M12x50 4x M12x50 4x M12x50 4x M12x75
32 4x M16x100 4x M16x55 4x M16x55 4x M16x55 4x M16x55 4x M16x55 4x M16x85
40 4x M16x110 4x M16x55 4x M16x55 4x M16x55 4x M16x55 4x M16x55 4x M16x90
50 4x M16x120 4x M16x55 4x M16x55 4x M16x55 4x M16x55 4x M16x55 4x M16x100
65 4x M16x140 4x M16x55 4x M16x55 4x M16x55 4x M16x55 4x M16x55 4x M16x100
80 8x M16x160 8x M16x60 8x M16x60 8x M16x60 8x M16x60 8x M16x65 8x M16x110
100 8x M16x180 8x M16x65 8x M16x65 8x M16x65 8x M16x65 8x M16x65 8x M16x120
125 8x M16x200 8x M16x65 8x M16x65 8x M16x65 8x M16x65 8x M16x70 8x M16x160
150 8x M20x240 8x M20x70 8x M20x70 8x M20x70 8x M20x70 8x M20x75 8x M20x175
200 12x M20x80 12x M20x75 12x M20x75 12x M20x75 12x M20x75 12x M20x75 12x M20x220
250 - - - 12x M24x85 12x M24x85 12x M24x85 -
300 - - - 12x M24x85 12x M24x85 12x M24x90 -
350 - - - 16x M24x95 - - -
Table44: Bolt sizes and lengths to DINEN1092-2 PN25
DN BOA-SuperCompact
35)
5.1301
36)
BOA-Compact
37)
5.1301
36)
BOA-W
5.1301
36)
BOA-H
5.3103
38)
BOA-R BOA-S
5.3103
38)
BOA-RVK
15 - - - 4x M12x50 - 4x M12x50 -
20 - - - 4x M12x50 - 4x M12x50 -
25 - - - 4x M12x50 - 4x M12x50 -
32 - - - 4x M16x55 - 4x M16x55 -
40 - - - 4x M16x55 - 4x M16x55 -
50 - - - 4x M16x60 - 4x M16x60 -
65 - - - 8x M16x65 - 8x M16x65 -
80 - - - 8x M16x70 - 8x M16x70 -
38) EN-GJS-400-18-LT (JS1025)
