8 Servicing/Maintenance
46 of 60
Table38: Bolt tightening torques, BOA-R [Nm]
PN Material DN
15 20 25 32 40 50 65 80 100 125 150 200 250 300
16 5.1301
33)
20 20 20 30 30 30 80 80 150 150 150 150 260 260
16 5.1301
33)
20 20 20 30 30 30 80 80 150 150 150 150 260 260
25 5.3103
34)
20 20 20 35 35 35 90 90 170 170 170 170 290 290
Table39: Bolt tightening torques, BOA-S [Nm]
PN Material DN
15 20 25 32 40 50 65 80 100 125 150 200 250 300
6 5.1301
33)
10 10 20 20 20 20 30 30 30 30 30 80 - -
16 5.1301
33)
20 20 20 20 30 30 80 80 80 80 80 80 150 150
16 5.3103
34)
20 20 20 20 35 35 90 90 170 170 170 170 290 290
25 5.3103
34)
20 20 20 20 35 35 90 90 90 90 90 90 - -
Table40: Bolt tightening torques by thread size [Nm]
Thread size Body material/bolt material
EN-GJL-250
5.6/8.8
EN-GJS-400-18-LT
CE35E/1.7709
M8 10 -
M10 20 20
M12 30 35
M16 80 90
M20 150 170
M24 260 290
8.2.5 Bolt lengths for flange connections
Connecting elements are needed to install a valve in a pipeline. These are bolts and
nuts. For BOA-SuperCompact fully threaded studs with nuts can also be used (see
type series booklet 7113.1).
The bolts and nuts must be selected in accordance with DINEN1515-4 "Flanges and
their joints, Part4, Selection of bolting". In order to ensure the correct installation of
the valve, the bolts and nuts must be made of the materials defined by this standard
as a function of pressure and temperature for use within the scope of the Pressure
Equipment Directive 2014/68/EU.
The bolt lengths are specified without considering tolerances; they refer to the
installation of a valve in a pipe with a standardised steel mating flange to
DINEN1092-1.
The number of bolts, their thread size and length are specified for the respective
valve series and nominal pressures. This data can also be obtained via KSB's flange
selector (reference No. 0570.3).
Table41: Bolt sizes and lengths to DINEN1092-2 PN6
DN BOA-SuperCompact
35)
5.1301
36)
BOA-Compact
37)
5.1301
36)
BOA-W
5.1301
36)
BOA-H
5.1301
36)
BOA-R
5.1301
36)
BOA-S
5.1301
36)
BOA-RVK
15 - 4x M10x35 4x M10x35 - 4x M10x40 4x M10x35 4x M10x55
20 4x M10x80 4x M10x40 4x M10x40 - 4x M10x45 4x M10x40 4x M10x60
25 4x M10x80 4x M10x40 4x M10x40 - 4x M10x45 4x M10x40 4x M10x65
32 4x M12x90 4x M12x45 4x M12x45 - 4x M12x50 4x M12x45 4x M12x75
40 4x M12x100 4x M12x45 4x M12x45 - 4x M12x50 4x M12x45 4x M12x75
50 4x M12x110 4x M12x45 4x M12x45 - 4x M12x50 4x M12x45 4x M12x90
65 4x M12x120 4x M12x45 4x M12x45 - 4x M12x50 4x M12x45 4x M12x90
35) Refer to type series booklet 7113.1 for further connection options
36) EN-GJL-250 (JL1040)
37) Also for BOA-CompactEKB and BOA-ControlIMS
