1 Constant level oiler 2 Vent plug
3 Connection elbow of the constant
level oiler
4 Screwed plug
5 Bearing bracket
1. Pull out the vent plug (2).
2.
Hinge down the reservoir of the constant level oiler (1) from the bearing bracket
(5) and hold in this position.
3. Fill in oil through the hole for the vent plug until the oil reaches the connection
elbow of the constant level oiler (3).
4. Completely fill the reservoir of the constant level oiler (1).
5. Snap the constant level oiler (1) back into its operating position.
6. Fit the vent plug (2) again.
7. After approximately 5 minutes, check the oil level in the glass reservoir of the
constant level oiler (1).
The oil reservoir must be properly filled at all times to provide an optimum oil
level. Repeat steps 1 - 6, if necessary.
8. To check the function of the constant level oiler (1), slowly drain some oil via the
screwed plug (4) until air bubbles can be seen in the oil reservoir.
NOTE
An excessively high oil level can lead to a temperature rise and to leakage of the fluid
handled or oil.
6.1.3 Shaft seal
Shaft seals are fitted prior to delivery.
Observe the instructions on dismantling (⇨ Section 7.4.6 Page 53) or reassembly (⇨
Section 7.5.4 Page 56) .
If applicable, fill the reservoir of non-pressurised external fluid in accordance with
the general arrangement drawing.
Prior to starting up the pump, apply barrier pressure or supply flushing/quench liquid
as specified in the general arrangement drawing.
Apply the quantities and pressures specified in the data sheet and the general
arrangement drawing.
6.1.4 Filling and venting the pump
DANGER
An explosive atmosphere forms inside the pump
Explosion hazard!
▷ The pump internals in contact with the fluid to be handled, including the seal
chamber and auxiliary systems must be filled with the fluid to be handled at all
times.
▷ Provide sufficient inlet pressure.
▷ Provide an appropriate monitoring system.
DANGER
Shaft seal failure caused by dry running
Hot or toxic fluid could escape!
Damage to the pump!
▷ Before starting up the pump set, vent the pump and suction line and fill both
with the fluid to be handled.
1. Vent the pump and suction line and fill both with the fluid to be handled.
Reservoir of non-
pressurised external fluid
Double-acting mechanical
seal
External liquid feed
6 Commissioning/Start-up/Shutdown
KWP
39 of 78
