Part No. Description Scope of supply
101 Pump casing
with joint ring 411.01
24)
/.02
24)
/.031
24)
/.10, hexagon head bolt 901.01, stud
902.01, screwed plug 903.01
24)
/.02
24)
/.03
24)
, hexagon nut 920.01
135.01
25)
Wear plate with joint ring 411.13, O-ring 412.05/.75, hexagon head bolt 901.03,
socket head cap screw 914.05
163
26)
Discharge cover (A-type
cover)
163 Discharge cover (with
bolted on stuffing box
housing)
with gasket 400.05, joint ring 411.26, hexagon head bolt 901.22
183 Support foot with socket head cap screw 914.04, spring washer 930.01
210 Shaft with keywayed nut 920.21, lockwasher 931.01, key 940.01/.02
230 Impeller with gasket 400.04
320.02 Angular contact ball
bearing
322.01 Cylindrical roller bearing
330 Bearing bracket
330 Bearing bracket,
complete
with bearing cover 360.01, bearing carrier 382, gasket 400.01, joint ring
411.46, O-ring 412.02, lip seal 421.01/.02, support disc 550.23, constant
level oiler 638, vent plug 672, screwed plug 903.46, socket head cap screw
914.01/.02, circlip 932.01/.03
344 Bearing bracket lantern with forcing screw 901.31, stud 902.04, hexagon nut 920.04
360.01 Bearing cover with gasket 400.01, socket head cap screw 914.01
382 Bearing carrier with O-ring 412.02, grub screw 904.01, socket head cap screw 914.02,
circlip 932.03
421.01/.02 Lip seal
433.02 4K mechanical seal with O-Ring 512.51/52, spring-loaded ring 472.53, thrust ring 474.53, seat
ring 475.52, spring 477.53, socket head cap screw 914.53, shaft sleeve
523.01
451.01
24)
Stuffing box housing with gasket 400.05, joint ring 411.16/.17/.18/.19/.26, drip plate 463.01, disc
550.01, stud 902.02, screwed plug 903.16/.17/.18/.19, hexagon nut 920.02
452.01
24)
Gland follower
454.01
24)
Stuffing box ring, split
456.01
24)
Neck bush
458.01
24)
Lantern ring, split
461.01
24)
Packing ring
507.01 Thrower
524.01 Shaft protecting sleeve with O-ring 412.06
906 Impeller screw with O-ring 412.03
99-9 Set of sealing elements with gasket 400.01/.02/.03/.04, joint ring 411.01/.02/.03/.10/.13/.46, O-ring
412.02/.03/.05/.06/.75
24)
If any
25)
For 250-315, the wear plate is replaced by casing wear ring 502.01.
26)
Models with mechanical seal
9 Related Documents
72 of 78
