lares 4.0 Programming manual
R30024.130en 10
1.4 How to update firmware version
Update firmware version in local network connection :
• from PC / MAC, by clicking on the button <Load update file> in the Home Page -> Panel software section, it is
possible to load the update file.
WARNING! This function is available from version FW 1.46.20. Previous versions must use the SD card with the following
requirements: maximum capacity 32Gb, FAT 32 formatting, the file containing the FW must be present in the main root.
Update firmware version in remote network connection:
• In the Home Page-> Panel software section, click on “Update software” icon . It is displayed only when a
new version is available for download and installation.
1.5 How to save the configuration
The control panel reads both .bck files which only contain the control panel programming backup (for backwards
compatibility), and .ksa files which can always contain the configuration of the control panel and eventually, the
knx.json file which contains the configuration of the konnex device.
