3.9.8 SIA IP Receivers
For each receiver, a possible backup receiver, on which the signals are sent in case of communication failure with the
main receiver, is also created. Then enter the various parameters:
The device allows sending signals to a primary receiver, and possibly to an optional secondary backup. The following
data is valid for both receivers, but only mandatory for the primary receiver.
RICEIVER AND BACKUP RECEIVER
Description Give a name to the SIA-IP receiver
Enable Eth/GPRS
supervision
By selecting this option, in case of availability of both Ethernet connection and
GPRS, supervisory packets are sent to the receiver using both the available
communication channels alternately.
Transmit over TCP Selecting this option sets the use of TCP instead of UDP protocol to send signals
Use Timestamp If selected, this option sets the presence of information related to date and hour
on the data packet.
Communication timeout Waiting time in seconds necessary to receive confirmation of the signal sent to
the receiver before the control panel makes a further attempt (default 5,
maximum 60)
Ethernet port Local port on which the control panel is listening when the message is sent via
Ethernet
Ethernet supervision
interval (sec.)
The time interval in seconds between a supervisory package and the other via
the Ethernet channel.
GPRS supervision interval The time interval in seconds between a supervisory package and the other via
the GPRS channel.
Supervision mode Select which receivers should be supervised (Select the 'Only one' option if you
want to supervise only the main receiver, and 'All' if you want to supervise both)
Protocol Application protocol used to format the data field of the transporting protocol
SIAIP DC09 (SiaLevel3, KS-PROT for compatibility with the Vigilo receiver).
Application Status ID ID of the control panel's application protocol used with the current receiver.
Transporting Layer ID SIA-IP DC09 ID of the control panel used with the current receiver, maximum 12
hexadecimal digits.
Ethernet IP The IP address of the receiver to be used when a message is sent via Ethernet
Ethernet port The remote port through which the receiver listens when a signal is sent via
Ethernet
GPRS IP The IP address of the receiver to be used when a message is sent via GPRS
GPRS port The remote port through which the receiver listens when a message is sent via
GPRS
Receiver ID SIA-IP DC09 identifier of the receiver, maximum 6 hexadecimal digits
