Appendix 3. Option
1. Extended battery box
2. Dry contact card
3. SNMP card
4. Parallel card
Appendix 4. UPS message table
01（running）
02：（status）
8 9 A B C D E F EPO
4 5 6 7 C D E F Rectifier working
2 3 6 7 A B C E F Rectifier limit
1 3 5 7 9 B D F Input normal
8 9ABCDEF
Input 1：main /0：battery
4 5 6 7 C D E F charging
2 3 6 7 A B C E F P-battery boost charging
1 3 5 7 9 B D F N-battery boost charging
8 9 A B C D E F Battery self-testing
4 5 6 7 C D E F
2 3 6 7 A B C E F
00：shutdown；01：soft start；
0：no out
p
ut；11：out
p
ut normal
1 3 5 7 9 B D F Alarm for switching delay
0x01 No output
0x02 on bypass
0x03 on online
0x04 on battery
0x05 Battery self-testing
0x06 Inverter starting
0x07 ECO mode
0x08 EPO
0x09 maintenance bypass
0x0A Fault
