UPS Messages reference table
Explanation Content
Initialization CurState: Init
No export No-Out
At bypass Bypass
Rectifier working Mains
Battery mode Battery
Battery testing Testing
Starting Starting
ECO mode CurState : ECO
EPO mode CurState: EPO
UPS maintaining CurState: M-Byp
UPS fault CurState:Fault
Battery float charging Battery Charging
Battery Boost charging Battery Boost
Inverter on/off Invter ON/ Invter OFF
Master of UPS Inver Master
Maintenance switch close or open SWMB ON/ SWMB OFF
1.5.3 Display instruction
1) The main interface below comes out when the power is connected or the system is
cold start. See Fig1
Fig.1：Main interface
2) Press any key, it will change to the basic status interface , see Fig2 below
Fig.2：Basic status interface
Welcome
10KVA
Mode:On-Line
Battery 7AH
Vin 220V 50Hz
Vout 220V 50Hz
To Next Page
