3) Press the ◀ or ▶ button, it will change to main menu, see Fig3，
Fig.3： Main menu
4) An arrow icon will come out on the LCD when pressing the ENT, then, the data info,
status info, setting info, command control can be selected by pressing the right or left
arrow button, and checking the details by pressing
5) Select and confirm the data info to be viewed in detail. It contains the details of the
AC input /output, inverter, battery, BUS, parallel, temperature. See Fig 4 to 12
below.
Fig.4：MAIN INPUT INFO Fig.5：OUTPUT INFO Fig.6：OUTPUT INFO
Fig.7：INVERT INFO Fig.8：BATTERY INFO Fig.9 BATTERY INFO
Fig.10：BUS INFO
Fig.11：PARALLEL INFO
Fig.12：TEMPERATURE
INFO
Figure
Status
Setting
Command
Figure
Mains
220.0V 0.0A
50.0Hz
Figure
Output
220.0V 0.0A
50.0Hz
0%
Figure
Output
0.0KW PAK: 0.0
0.0KVA
Figure
Invert
220.0V
50.0Hz
Figure
PBatt. Discharge
0V 0.0A
0% 0min
Figure
NBatt. Discharge
0V 0.0A
0% 0min
Figure
BUS
-390V +390V
Figure
Parallel ID
ID:01
Figure
Temperature ℃
Inner:24
REC:24 INV:30
To Next Page
