- 11 -
6) Select and confirm the status info can view the details, including status information,
alarm information, code, power rating and version. See Fig 13 to 14
Fig.13：main menu Fig.14：main menu
Fig.15：status info Fig.16：Alarm info Fig.17：type info
Fig18：code info Fig19：version info
7) Select and confirm setting menu , setting information will be displayed on the screen,
which includes user set, system set, parallel set, battery set, revise set.
Fig.20：setting menu Fig.21：setting menu
 Select and confirm client setting, then see Fig. 22.
Fig.22：user setting information
Status
State
Alarm & Fault
Rated POWER
Status
Rated POWER
Code
Version
Status
State
CurState:Init
SWMB OFF

Status
Alarm & Fault

Status
Rated POWER
MachInfo:0101
Rated: 10KVA
Status
Code/Status
01 0x00
02 0x000000
Status
Version
LCD Ver. D000B001
DSP Ver. D000B001
Setting
User set
System set
Parallel set

Setting
Battery set
Revise set

Setting
User set
BL. 60sec
Contrast 2
