15 WHEELS, TIRES
192
K00540-11
– Operate the front brake and compress the fork a few times
firmly.
The fork legs straighten.
–
Tighten screws
8
.
Guideline
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Finishing work
– Install the bottom triple clamp cover. ( p. 147)
15.3 Removing the rear wheel
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 126)
