KTM 1290 SUPER DUKE R 2023 User Manual

3 WORK
8
3.1 Removing the passenger seat (SUPER DUKE R)
S03911-10
– Insert the RACE ON key or the black ignition key into seat
lock
1
and turn it clockwise.
– Lift passenger seat at the front and pull it out of the bracket
toward the front.
– Remove the passenger seat.
– Remove the ignition key.
3.2 Mounting the passenger seat (SUPER DUKE R)
S03912-10
–
Hook recesses
1
of the passenger seat in guides
2
and
lower the front seat while pushing it back.
– Position the locking pin in the lock housing and push the pas-
senger seat down at the front.
The locking pin engages with an audible click.
– Check that the passenger seat is mounted correctly.
3.3 Removing the front rider's seat
Preparatory work
(SUPER DUKE R)
– Remove the passenger seat. ( p. 8)
S03913-10
Main work
–
Unlock the front rider's seat with loop
1
underneath the pas-
senger seat.
– Raise the front rider's seat at the rear and remove it.

KTM 1290 SUPER DUKE R 2023 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Transmission	6-speed
Cooling	Liquid-cooled
Fuel Tank Capacity	16 liters
Seat Height	835 mm
Dry Weight	189 kg
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.5:1
Fuel System	Electronic fuel injection
Final Drive	Chain
Rear Suspension	WP APEX monoshock
Traction Control	MTC (Motorcycle Traction Control)
Wheelbase	1482 mm
Power	132 kW (180 hp)
Torque	140 Nm
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP APEX 48
Front Brake	2 x Brembo Stylema Monobloc four-piston calipers, 320 mm discs
Rear Brake	Brembo two-piston caliper, 240 mm disc
ABS	Bosch 9.1 MP (incl. Cornering-ABS and Supermoto mode)
Electronics	Cruise Control
