KTM 1290 SUPER DUKE R 2023 User Manual

1 MEANS OF REPRESENTATION
2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
Indicates the end of an activity including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

KTM 1290 SUPER DUKE R 2023 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Transmission	6-speed
Cooling	Liquid-cooled
Fuel Tank Capacity	16 liters
Seat Height	835 mm
Dry Weight	189 kg
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.5:1
Fuel System	Electronic fuel injection
Final Drive	Chain
Rear Suspension	WP APEX monoshock
Traction Control	MTC (Motorcycle Traction Control)
Wheelbase	1482 mm
Power	132 kW (180 hp)
Torque	140 Nm
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP APEX 48
Front Brake	2 x Brembo Stylema Monobloc four-piston calipers, 320 mm discs
Rear Brake	Brembo two-piston caliper, 240 mm disc
ABS	Bosch 9.1 MP (incl. Cornering-ABS and Supermoto mode)
Electronics	Cruise Control
