KTM 1290 Super Duke R Setup Instructions

2 SETUP
6
S04150-01
– Carefully loosen and remove the tension belts around the fork
legs.
The vehicle is released at the front.
Info
An assistant prevents the motorcycle from falling over.
– Remove the cable ties on either side of the footrest.
– Together with an assistant, take the vehicle off the pallet.
– Remove the radiator shield.
S04184-10
– Remove the passenger seat. ( p. 7)
– Remove the front rider's seat. ( p. 7)
– Remove the black ignition key and KEYCODECARD and keep in a
safe place for the handover.
–
Remove cover
bk
.
–
Plug in the connector of starter relay
bl
.
– Mount the cover.
– Charge the 12-V battery. ( p. 11)
– Remove the protective film.
– Refuel. ( p. 13)
– Prepare the vehicle according to the specifications in
KTM Dealer.net for handover to the customer.

KTM 1290 Super Duke R Specifications

General

Displacement	1301 cc
Transmission	6-speed
Seat Height	835 mm
Fuel Tank Capacity	16 liters
Dry Weight	189 kg
Starter	Electric starter
Fuel System	Electronic fuel injection
Traction Control	MTC (Motorcycle Traction Control), lean-angle sensitive
Wheelbase	1482 mm
Front Tire	120/70 ZR 17
Rear Tire	200/55 ZR 17
Engine Type	V-Twin, 4-stroke
Power	180 hp (132 kW) @ 9500 rpm
Torque	140 Nm
Frame	Chromium-Molybdenum steel frame, powder coated
Front Suspension	WP APEX 48
Rear Suspension	WP APEX monoshock
Rear Brake	Brembo two-piston caliper, 240 mm disc
Front Brake	Dual 320 mm discs, Brembo Stylema monobloc calipers
ABS	Bosch 9.1 MP (incl. Cornering-ABS and Supermoto mode)
