ELECTRICAL SYSTEM 139
B00645-10
– Turn bulb socket counterclockwise all the way and take it out of the tail light.
– Push the bulb carefully into the socket, turn it counterclockwise, and pull it out of the
socket.
– Press the new bulb carefully into the socket and turn it clockwise until it stops.
Brake light (P21W/socket BA15s) ( p. 196)
– Insert the bulb socket into the tail light and turn clockwise until it stops.
– Check that the brake light system is functioning properly.
B00644-10
– Position the rear top part.
– Mount and tighten screws .
Guideline
Remaining chassis screws M5 5 Nm (3.7 lbf ft)
Remaining frame bolts EJOT PT K50x18
T20
2 Nm (1.5 lbf ft)
