SERVICE WORK ON THE CHASSIS 86
10.10Positioning the fuel tank
– Carefully push the fuel tank forward.
The fuel tank fixations must engage in the recesses.
B00670-10
– Install and tighten screw with the bearing sleeve and rubber bushing on both sides.
Guideline
Remaining chassis screws M8 25 Nm
(18.4 lbf ft)
– Check the routing of the fuel lines.
B00669-11
– Position the spoilers on both sides. Mount and tighten screws .
Guideline
Screw, spoiler M6 3.3 Nm
(2.43 lbf ft)
– Install the mask spoiler. ( p. 88)
– Mount the seat. ( p. 84)
