TUNING THE CHASSIS 75
B00618-11
– Turn adjusting screws clockwise all the way.
Info
The adjusting screws are located at the top end of the fork legs.
Make the same adjustment on both fork legs.
– Turn back counterclockwise by the number of turns according to the fork type.
Guideline
Spring preload - Preload Adjuster
Comfort 5 turns
Standard 5 turns
Sport 3 turns
Full payload 3 turns
Info
Turn clockwise to increase preload; turn counterclockwise to reduce spring
preload.
Changing the spring preload has no influence on the rebound damping although
the adjusting screws turn during the adjustment work. However, you should also
adjust the rebound damping when you alter the spring preload.
