11.13 Connections
Supply voltage and outputs:
Plug-in screw terminal, 8-pin, RM5.00
Core cross - section, max. 2.5 mm²
Signal and control inputs:
Plug-in screw terminal, 9-pin, RM 3.50
Core cross - section, max. 1.5 mm²
12 Scope of Delivery
Preset counter
Mounting clip
Instruction manual
13 Ordering Codes
6.560.X1X.XX0
Input trigger levels
0 = Standard level (HTL)
A = 4…30 V DC level
Supply voltage
0 = 90 .. 260 VAC
3 = 10 .. 30 VDC
Outputs
0 = Relays
Front
0 = Kübler version
A = Neutral version
14 Frequencies (typical)
NOTE: Switching levels of the inputs
Switching levels with AC supply:
HTL level Low: 0 .. 4 VDC
High: 12 . 30 VDC
4…30 V DC level Low: 0 .. 2VDC
High: 3.5. 30 VDC
Switching levels with DC supply:
HTL level Low: 0 .. 0.2 x UB
High: 0.6 x UB .. 30 VDC
4…30 V DC level Low: 0 .. 2 VDC
High: 3.5 .. 30 VDC
14.1 Pulse Counter
HTL level, signal shape square wave 1:1
AC supply typ. Low 2.5 V
typ. High 22 V
DC supply 12V typ. Low 2 V
typ. High 10 V
DC supply 24V typ. Low 2.5 V
typ. High 22 V
Add
Sub
Trail
AddAr
SubAr
AddBat
SubBat
TrailAr
AddTot
SubTot
Cnt.Dir 55 kHz 2.6 kHz 2.5 kHz
Up.Dn ; Up.Up 29 kHz 2.6 kHz 2.5 kHz
Quad ; Quad 2 28 kHz 1.2 kHz 1.1 kHz
Quad 4 18 kHz 1.1 kHz 0.8 kHz
A/B ; (A-B)/A 29 kHz
4…3
0 V DC level, signal shape square wave 1:1
typ. Low 1.0 V
typ. High 4.0 V
Add
Sub
Trail
AddAr
SubAr
AddBat
SubBat
TrailAr
AddTot
SubTot
Cnt.Dir 9 kHz 2.5 kHz 2.2 kHz
Up.Dn ; Up.Up 9 kHz 2.5 kHz 2.2 kHz
Quad ; Quad 2 9 kHz 1.1 kHz 1.1 kHz
Quad 4 9 kHz 1.1 kHz 0.9 kHz
A/B ; (A-B)/A 9 kHz
14.2 Frequency Meter
HTL level, signal shape square wave 1:1
AC supply typ. Low 2.5 V
typ. High 22 V
DC supply 12V typ. Low 2 V
typ. High 10 V
DC supply 24V typ. Low 2.5 V
typ. High 22 V
4…30 V DC level, signal shape square wave 1:1
typ. Low 1.0 V
typ. High 4.0 V
HTL 5V
A 65 kHz 9 kHz
A – B ; A + B
A / B ; (A-B)/A
65 kHz 9 kHz
Quad 30 kHz 9 kHz
