DIESEL
ENGINE
OS
SERIES
WSM,
01640
lightening
torque
Connecting
rod
screw
-.
16
41.2
to
46.1
Nm
4.2
to
4.7
kgfm
30.3
to
33.9
ft-lbs
w
L
I
1900F10380
01640P10160
I
1
1
(a)
Mark
Piston
~
___
1
7900s 10191
1.
Turn the flywheel and bring the No.
1
piston
to
the top dead
2. Pull out the piston upward by lightly tapping
it
from the bottom of
(When reassembling)
Before inserting the piston into the cylinder, apply enough engine
oil to the cylinder.
When inserting the piston into the cylinder, face the mark on the
connecting rod to the injection pump.
IMPORTANT
Do
not change
the
comblnation
of
cylinder and piston.
Make sure
of
the
position
of
each piston by marking. For
example, mark
"1
"
on the
No.1
piston.
When inserting the piston into the cylinder, place
the
gap
of
the compression ring
1
on
the opposite
side
of
the
combustion chamber and stagger the gaps
of
the
compression ring
2
and
oil
ring making
a
right
angle
from
the gap
of
the
compression ring
1.
Carefully Insert the pistons using
a
piston ring compressor
(1).
Otherwise, their chrome-plated section may
be
scratched, causing trouble inside the
liner.
(6)
Second
Ring
Gap
(C)
Oil Ring
Gap
(D)
Piston Pin
Hole
center.
the crankcase with the grip
of
a hammer.
(1)
Piston Ring Compressof
(A)
Top
Ring
Gap
11900S10201
s-97
Redistribution or publication of this document,
by any means, is strictly prohibited.
