REGULAR CHECKS AND MAINTENANCE WORK78
BChecking Fuel Line and Intake Air Line
1. Check to see that all lines and hose clamps are
tightened and not damaged.
2. If hoses and clamps are found worn or damaged,
replace or repair them at once.
AIR CONDITIONER
BCleaning Air Filter
Open the cover under the operator’s seat and remove the
filter cover, remove the air filter.
To avoid personal injury or death:
A Wear eye protection.
C Cleaning the air filter
A Normal use
Blow air from the opposite direction to the filter's
normal air flow.
A Do not hit the filter. If the filter becomes deformed, dust
may enter into the air-conditioner, which may cause
damage and malfunction.
(1) Fuel lines
(2) Clamp bands
(1) Hoses
(2) Hose clamps
(1) Air filter
(2) Filter cover
To Next Page
