GENERAL SYMBOLS
The instruments and operation elements have been marked with a series of symbols in order to simplify the operation of
your excavator. These symbols are listed below with the respective descriptions.
Safety alert Symbol
Warning lamp "Fuel level too low"
System lamp
Warning lamp "Battery charge"
Indicator lamp "Glow"
Working light switch
Horn
Wiper/Washer switch
Diesel
Hydraulic fluid
Gear oil
Grease
Fast
Slow
Excavator - Overhead movement toward the front
Excavator - Overhead movement toward the rear
Boom up
Boom down
Arm up
Arm crowd
Bucket crowd
Bucket dump
Boom swing (Left)
Boom swing (Right)
Dozer raise
Dozer lower
Operation direction of control lever
Operation direction of control lever
Read operator’s manual
Lock
Unlock
Engine stop control lamp
DPF Standby / Regeneration
Engine Idle up
Inhibit DPF Regeneration
