4 SPECIFICATIONS
Hydraulic
unit
Hydraulic control system Electronic draft control
Pump capacity L/min 70.9 77.2
Three point hitch Category 2
Max.
lifting
force
At lifting
points
kg
5000 At lower link end with links
horizontal
6100 At lower link end with links
horizontal
24 in.
behind
lifting
point *2
kg 4300 4900
Remote hydraulic control 2 standard (3rd & 4th valve optional)
System pressure
MPa
(kgf/cm )
19.6 (200)
Traction system Swinging drawbar, adjustable in direction
PTO
Live PTO
(Indepen-
dent)
Direction of turning Clockwise, viewed from tractor rear
PTO/
Engine
speed
rpm
6 splines:
540 / 2405
1000 / 2529
6 splines:
540 / 1994
1000 / 2050
The company reserves the right to change the specifications without notice.
NOTE: *1 Manufacturer's estimate
*2 Top link mounting: upper hole
< >: Front suspension type
Model
M100GX M110GX M126GX M135GX
4WD
