OC60-E2, OC95-E2, WSM DIMENSIONS
9
B X TYPE (WITH STOP SOLENOID) [OC95-E2]
STANDARD TYPE X TYPE
A 503 mm (19.81 in.) 503 mm (19.81 in.)
B 501 mm (19.73 in.) 501 mm (19.73 in.)
C 452 mm (17.80 in.) 452 mm (17.80 in.)
D 145 mm (5.71 in.) 145 mm (5.71 in.)
E 135 mm (5.32 in.) 135 mm (5.32 in.)
F 170 mm (6.69 in.) 170 mm (6.69 in.)
G 3 mm (0.12 in.) 3 mm (0.12 in.)
H 57 mm (2.24 in.) 57 mm (2.24 in.)
I 43 mm (1.69 in.) 43 mm (1.69 in.)
J 145 mm (5.71 in.) 145 mm (5.71 in.)
K 110 mm (4.33 in.) 110 mm (4.33 in.)
0000009664E
