OC60-E2, OC95-E2, WSM ENGINE
S-38
A
Do not damage to the brush and commutator.
(When reassembling)
A
Apply grease (Denso No.50 or equivalent) to the parts indicated in the figure.
(a) Joint of Magnet Switch
(b) Drive Lever
(c) Teeth of Pinion Gear
(d) Armature Shaft
A
When installing the brush springs (19), from popping out like a bullet.
0000009252E
