51PERIODIC SERVICE
BGreasing
To avoid personal injury:
A Be sure to stop the engine and remove the key
before greasing.
Grease the following location.
(1) King pin (LH, RH)
(2) Center pin
(3) Front wheel (LH, RH)
(1) Motion control lever pivot bushing (LH, RH)
(1) Motion control lever contact position (LH, RH)
To Next Page
