KUHN FC 202 - Technical Specifications

- 11 -
FC 202 FC 202 R
Attachment 3-point cat. 2
Power requirement (at PTO). As from 55 hp (40 kW)
Transport position Pivoted to the rear in line with the tractor
- overall width 4’11" (1500 mm)
- overall length 8' 3" (2500 mm)
Working position To the rear right-hand side of the tractor
- overall width 10' 6" (3200 mm)
Cutting system 4 discs
- cutting width 6' 7" (2000 mm)
- work rate 3.7 to 5 acres/hr (1.5 to 2 hectares/hr)
Rotation of discs 2600 rpm
(min
-1
)
Conditioning system Rotor with free swinging 2 conditioning rollers
fingers,reversible and which exert contact
adjustable conditioning pressure on the crop
comb
Width of conditioning rotor 1250 mm (4’1") 1225 mm (4')
(finger type or roller type
conditioner)
Speed (rotational frequency) of 1000 rpm (min
-1
) 810 rpm (min
-1
)
the conditioning rotor (FC
finger type or roller type
conditioner)
PTO speed (rotational frequency) 540 rpm (min
-1
)
Swath adjustment 2 swath screens and 1 adjustable rear shield
Swath width 700 - 1300 mm (2’3" - 4’3")
Weight with PTO shaft 745 kg (1639 lbs) 804 kg (1769 lbs)
Primary PTO shaft with free wheel (overrun clutch)
Optional extra - Rigidified blades
- Signalling elements
- Additional suspension spring
(only for FC 202 R)
TECHNICAL SPECIFICATIONS
