- 24 -
I FC 202 (machines fitted with conditioning rotor complete with free swinging fingers
and an adjustable comb).
1. ADJUSTING THE COMB
The amount of conditioning is governed by the intersection of the flails and comb.
The comb, which is located above the rotor, has 5 different positions.
When in position 1, there is minimal conditioning effect (fig. 29).
When in position 5, there is maximum conditioning (fig. 29).
The comb is reversible and has 2 different conditioning surfaces.
2. REVERSING THE COMB SIDES (see removing the comb).
Natural grass, use with the pointed Legumes, delicate crops, clover,
side of comb towards the front of the lucerne (alfalfa), use round side
machine. of the comb.
The previous settings are a guide and not necessarily correct for each crop.
CONDITIONING
