10. - Maintenance and storage
GMD24-GMD28 / HD
63
KN226BGB_A
Disc mower
10.2.1 PTO shafts
Primary PTO shaft
- Place the machine in working position.
- Stop the tractor engine and remove ignition
key.
Before using the machine for the first time:
- Grease the transmission.
During intensive use with tractors of
maximum authorized power, it is
recommended to grease at closer intervals.
Configuration: Standard
Every 50 hours:
• (1): Cross-bars.
• (2): Guide rings.
• (3): Transmission tube.
Configuration: Free wheel
Every 50 hours:
• (1): Cross-bars.
• (2): Guide rings.
• (3): Guide rings.
• (4): Free wheel.
