KUHN GMD28 User Manual

92 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Original instructions

KN226BGB_A

Read carefully before starting the machine

Operator's manual

Disc mower

---A1025-70B00001 > ---A1025-70B99999

GMD24-GMD28 / HD

KN226BGB_A

- English - 07-2019

*KN226BGB_A*

Table of Contents

Questions and Answers:

D
Donna SmithAug 9, 2025
How to fix uneven stubble with KUHN GMD28 Farm Equipment?
- L
  Logan TuckerAug 9, 2025
  If you observe uneven stubble while using your KUHN Farm Equipment, it could be due to several reasons. The knives might be dull or broken, in which case you should replace them. Also, check if the knives are installed correctly, ensuring the arrow on the knife's upper face points in the disc's direction of rotation. Insufficient disk speed can also cause this issue, so check the belt tension. Finally, ensure that the PTO speed is adequate, and increase it to 540/min if it is too low.
D
daniellereyesAug 19, 2025
What to do if soil builds up in front of the cutterbar on my KUHN GMD28?
- T
  Travis NguyenAug 20, 2025
  If you find soil building up in front of the cutterbar of your KUHN Farm Equipment, it may be due to very wet working conditions. Adjust the main frame height with regards to the ground and consider fitting raised skid shoes. Alternatively, there might be too much cutterbar down pressure, in which case you should fit a compensating spring.
L
Lauren SimonAug 29, 2025
Why is the ground contour adaptation bad on my KUHN Farm Equipment?
- J
  Jerry SteeleAug 30, 2025
  Poor ground contour adaptation with your KUHN Farm Equipment can arise from several factors. First, ensure that the main frame is set correctly by adjusting its height relative to the ground. Excessive ground speed can also be a cause, so reduce your speed. Check the condition of the cutter bar pivot bushes for wear or seizure, and replace them if necessary. Lastly, a blocked hydraulic cylinder can cause this, so set the hydraulic valve in a floating position.
