6. - Putting into service
GMD24-GMD28 / HD
41
KN226BGB_A
Disc mower
Never operate the PTO shaft at an angle X
exceeding 30°.
To avoid serious accidents, the PTO drive
shaft guards must be properly in place and
fixed with the chains provided.
- Attach PTO shaft guard using chain provided in
order to prevent it from rotating.
- Immediately replace any worn or damaged
guard.
6.2.9 Adjusting the machine
Positioning of lower links
- Measure dimension E.
- Adjust the side stabilizers of the tractor's lower
links to obtain a measure E of 50 mm (2").
