7. - Instructions for transport
GMD24-GMD28 / HD
47
KN226BGB_A
Disc mower
7. Instructions for transport
7.1 Putting the machine into
transport position
From the working position:
- Lift the machine with the tractor's three point
linkage.
- Remove lynch pin (1) and pin (2).
- Lock compensation system in transport position
using pin (2) and lynch pin (1).
- Pull handle (1) to unlock front guard.
- Raise front guard until lock is automatically
engaged.
- Lift the machine using the tractor's lift linkage.
Before placing the machine into transport
position:
- Check that nobody is within the machine
pivoting area.
- If there is someone, make sure the person
moves away.
