6. - Putting into service
GMD24-GMD28 / HD
45
KN226BGB_A
Disc mower
6.2.10 Uncoupling the machine
From the transport position:
- Lift the machine with the tractor's three point
linkage.
- Check that lock (1) of the suspension system is in
transport position.
- Activate single acting valve of transport/work
positioning cylinder to lighten pressure on
transport lock.
- Pull the release cord until transport lock is
released.
- Place the single acting valve of the mowing unit lift
cylinder in floating position to lower the mowing
unit.
- For tractors not fitted with a hydraulic
position control function, unhook check
chain.
The machine must be uncoupled in working
position.
