Clean the nut case.
Remove nut (1).
Remove spring washer (2).
On cone disks:
Reinstall plug (1).
Remove nut (2).
Remove spring washer (3).
Note the direction of the spring washer.
Note the direction of the spring washer.
Step 2.
Page 26/95Printing date : 06-02-2014 GMD44_760001_xxxxxx
