Main operations
Remove disk (1).
Remove fender washer (2).
Note direction of fender washer.
For easier removal, use levers on either sides of the
disk.
Step 1.
Parking
Remove cutterbar from the chassis.
Remove 4 bolts (1).
Remove brackets (2).
Remove side skids (3).
