Main operations
Remove circlip (1).
Remove drive pinion (2).
Remove circlip (1).
Remove bearing (2).
Step 10.
Replace all parts that are worn or damaged with KUHN original parts.
Step 1.
Fitting
Clean components before reinstalling them.
Page 34/95Printing date : 06-02-2014 GMD44_760001_xxxxxx
©Copyright KUHN S.A.
