1) After putting the Piano Body on each side of the
stand, align the 4 holes in the stands with the holes
in the bottom of the Piano Body.
Before tighten up the bolts, do not press Piano
Body(especially for keys).
The body may fall forward.
2) Fix the Piano Body and Side Panel Stand by using
the Set Bolts
❻
.
3) Connect the Pedal Cable with the pedal terminal in
the Piano Body.
4) After decide the place for the piano, loose the
Pedal Bolt when it goes to the ground to avoid
damaging the Pedal Box with playing the piano.
Insert the pin until it makes a “Tick” sound. If the pin
is bent or is not completely connected, the Pedal will
not work.
● When the assembly is complete, connect the pedal cable to the port in the bottom of
piano body.
● If the pedal cable is not completely connected, the pedal will not work.
● Dress the pedal cable by using the cable clamps.
After decide the place for the piano, loose the pedal bolt when it goes to the ground to avoid
damaging the pedal box with playing the piano.
Assembling Left/Right Side Panel Stand
How to connect Pedal Cable
Caution
Unless you loose the Pedal Bolt, it can be damaged.
