Following the entry of the SATCONFIG and DEBUGON
commands, enter the satellite transponder information via PC as
follows:
Command: @SATCONFIG,X,N,F,S,C,ID,P,B,D<cr>
Where: @SATCONFIG = directs data to the RF Board
X = satellite location A or B
N = satellite table # (98 & 99 are slots for user-
configured satellites)
F = frequency in MHz (either 00000 or a range from
10700 - 12700)
S = the satellite transponder symbol rate in
Mbit/second (01000 - 30000)
C = the FEC code (e.g., 12, 23, 34, 56, 67, 78)
ID = the satellite network ID in hexidecimal format
(0x####)
P = the LNB polarization (v=vertical, h=horizontal)
B = the LNB down conversion frequency (l=low,
h=high)
D = decoding type (0=test, 1=DSS-A, 2=DSS-B,
3=DVB)
This information has to be entered for each of the four
transponder categories:
• vertical high • vertical low
• horizontal high • horizontal low
TracVision 4 requires that the data fields for all four transponder
categories be provided. If the selected satellite does not have
information for one or more of the transponder categories,
default information should be entered in the fields as follows:
Transponder Data Default Value
Frequency 00000
Symbol Rate 27500
FEC Code the same value as provided for those
transponders with data
Network ID 0x0000
Polarity and Band whichever combinations are not
already provided
2-15
Installation
54-0150 Rev. D
