KVH Industries TracVision 4 User Manual

Appendix B
TracVision 4 Baseplate
Mounting Holes Template
Drill 3/8" (10 mm)
Bolt Hole
9" (229 mm)
3" (80 mm)
Drill 3/8" (10 mm)
Bolt Hole
Drill 3/8" (10 mm)
Bolt Hole
Drill 3/8" (10 mm)
Bolt Hole
C
u
t
o
u
t
f
o
r
C
a
b
l
e
A
c
c
e
s
s
9" (229 mm)
9" (229 mm)
9" (229 mm)
