Current Cable Wrap Angle
Function: sets or reports current cable wrap angle, defined as
0° (CCW limit) to 700° (CW limit); the value is
expressed as 0000-7000 with an implied decimal
Command: WRAPANGLE,xxxx
Argument: the desired cable wrap angle setting
Response: Wrap Angle = xxxx
G.4 Tracking and Conical
Scan Commands
Target Location
Function: reports the target location in antenna frame. Data
format is E### for elevation in degrees 000-900
and A#### for azimuth in degrees 0000-3599 with
implied decimals
Command: TGTLOCATION
Argument: none
Response: Target Location= A = E###, A####
B = E###, A####
Analog Signal Strength Report
Function: reports signal strength from RF detector circuit in
A/D counts (000-FFF Hex)
Command: SIGLEVEL
Argument: none
Response: Signal Strength = xxxx
G-4
A Guide to TracVision 4
Table G-4
Tracking and Conical
Scan Commands
