KYMCO Mongoose 50-4T User Manual

17. BULBS REMOVAL/INSTRUMENT/HORN
17-2
INDICATOR LIGHTS
Remove the handlebar cover (see page 2-3)
and raise it.
Remove the bulb sockets by pulling them
out.
Pull the bulb out of the socket and replace it
with a new one.
Installation is in the reverse order of
removal.
POSITION LIGHT (ON ROAD ONLY)
Pull the bulb socket out of the position light
case.
Pull the bulb out of the socket and replace it
with a new one.
Installation is in the reverse order of
removal.
FRONT TURN SIGNAL LIGHT (ON
ROAD ONLY)
Remove the turn signal light lens by a flat
screwdriver.
Pull the bulb socket out from the signal light
case and remove bulb.
Install the bulb, aligning the bulb socket
groove with the bulb tab.
Bulb Socket
Turn Signal Light Lens
Bulb
Bulb
Bulb Socket
Bulb
Bulb Socket
