KYMCO Mongoose 90 Service Manual

9.DRIVE AND DRIVEN PULLEYS
9-6
Install the starter driven gear and friction
spring onto the left crankcase cover as the
figure shown.
Install the kick starter spindle cover and
tighten three bolts.
First install the washer and then install the
circlip.
Install the kick lever.
LEFT CRANKCASE COVER
INSTALLATION
First install the dowel pins.
Install the gasket.
Install the left crankcase cover and tighten the
eight left crankcase cover bolts diagonally.
Washe
r
Left Crankcase Cove
r
Starter Driven Gea
r
Friction S
p
rin
g
Circlip
Dowel Pins
Bolts
Kick Starter S
p
indle Cove
r
Apply grease on to the driven gear shaft.
＊
