2. FRAME COVERS/EXHAUST MUFFLER
2-8
Inspect the gasket.
If the exhaust gas leaks, the gasket should
be replaced.
Install by reversing the removal sequence.
Torque:
Exhaust muffler lock bolt
35 N-m (3.5 kgf-m, 25 lbf-ft)
Exhaust muffler lock nut (90cc/70cc/50cc-
2T)
20 N-m (2 kgf-m, 15 lbf-ft)
Exhaust muffler lock nut (50cc-4T)
10 N-m (1 kgf-m, 7 lbf-ft)
TAILLIGHT BULB
REMOVAL
Remove the two screws and taillight lens.
Turn bulb and remove it.
Be sure to install a new exhaust gasket.
＊
Gaske
To Next Page
