5
. FUEL SYSTEM
5-10
AIR CLEANER (50cc-2T)
CLEANING
Refer to “AIR CLEANER” section in the
chapter 3.
REMOVAL
Remove front fender. (See page 2-5)
Disconnect the air inlet hose from the frame.
Remove the bolt at the air cleaner left side.
Loosen the screw at the band and remove bolt at
the air cleaner right side, then remove air cleaner.
INSTALLATION
R
e
v
e
r
s
e
t
h
e
“
REMOVAL”
p
r
o
c
e
d
u
r
e
s
.
Air Inlet Hose
Bol
t
Bol
t
Screw
