KYMCO Mongoose 90

4. LUBRICATION SYSTEM
4-9
Bolts
N
u
t
Bolts
OIL PUMP (70cc/50cc-4T)
REMOVAL
Place a container under the engine.
Remove the drain plug to drain the oil (
page
3-9
).
Remove the A.C. generator flywheel (page
14-8).
Remove the A.C. generator stator and pulsar
coil (page 14-8).
Remove the eight right crankcase cover
bolts and the right crankcase cover.
Remove the oil pump gear nut and oil pump
gear.
Oil Pump Gea
r
N
u
t
Bolts
Right Crankcase Cove
r
