16. STARTING SYSTEM
16-1
STARTING CIRCUIT
Starter Moto
r
G
G/Y
Ignition Switch
Fuse
Stop Switches
R
Y/R
Battery
Starte
r
Motor
Starter Relay
Rea
r
G
R/W
Fron
t
G/Y
Stopligh
t
Star
t
Switch
