13
(11) Reservoir water tank
(12) Front brake fluid reservoir
(13) Right rearview mirror(Optional)
(14) Seat
Brake pedal fluid reservoir
Seat lock lever
Oil level inspection window
(18) Tool storage
(19) Left rearview mirror(Optional)
(15)
(16)
(17)
(16)
(17)(18)
(11)(12)
(13) (19)
(14)(15)
NOTE: Your scooter may differ slightly in appearance from the images in this manual.
